精品烤漆房大型烤漆房烤漆房,精品,昶晟
内尺寸 | 16350×4850×4400MM(L*W*H) | ||
Inside Dimension | |||
外尺寸 | 16500×500×5000MM(L*W*H) | ||
Outside Dimension | |||
正面门 | 单开门，大门4扇，4000×4000mm(W×H)，颜色：白色。 | ||
Main door | 4-fold,4000×4000MM(W×H),color:white. | ||
工作门 | 2扇，700×2000mm（W×H),颜色：白色。 | ||
Personal door | 2-fold,700×2000mm(W×H),inside is polystyrene,color:white. | ||
墙体 | 墙体中间配3组型钢加强筋，顶部配3组型钢组合梁。墙板采用厚75mm，里外δ=0.476mm彩钢板，插口型，宽950mm，内填物：EPS，颜色：白色。 | ||
Wall panel | 3 units supporting steel and 3 units profiled bar beam in the roof to strengthen the room body, wall panel thickness:75mm5,width:950mm5,tongue and groove structure,0.476mm color:white | ||
照明 | 上排灯18组×4支=72支36W灯管，配14组×4支=56支36W垂直腰灯。（左/6，右/6，后/2） | ||
Lighting | 18Units×4pcs=72Pcs×36W,side lights:14Units×4Pcs56Pcs×36W,Vertical(left side have 6 units,right side have 6 units,rear side have 2 units). | ||
机柜装置 | 侧上进风，后上排风，方管钢框架。外白色蒙板，内镀锌钢板蒙板。 | ||
Generator setting | Intake air from side upper direction,exhaust aie from back upper direction,quadrate steel frame,outside is white coated steel,inside is galvanized steel. | ||
送排风机座（2套） | 送风配4台双进风离心风机，单台风机型号和技术参数如下：型号：YDW5.6M,功率：7.5KW，流量：20000m³/h/台。 | ||
Intake and exhaust air systems 2units | 4Pcs7.5KWdouble-intake centrifugal fans for exhaust air,model YDW5.6M,air capacity is 20000m³/h for each fan. | ||
排风配2台双进风离心风机，单台风机型号和技术参数如下：型号：TAE-710H，功率11KW,流量：36000m³/h/台，皮带传动。 | |||
2Pcs 11KW double-intake centrifugal fans for exhaust air,model TAE-710H,belt-drive,air capacity is 36000m³/h for each fan. | |||
加热系统（2套） | 配2台利雅路G20型燃油燃烧器，2台不锈钢热交换器，2台电动风门执行喷烤漆循环。最大发热量：520000Kcal/h. | ||
Heating system | 2Pcs Riello G20 diesel burners,Maximum heat productivity;520000Kcal/H,2Pcs stainless steel heat wxchangers,2Pcs electeic dampers from spraying to baking cycle.Highest working temperature:80℃ | ||
2 units | |||
过滤系统 | 初效过滤，高效过滤 | ||
Filter system | Pre-filter,high efficiency filter(ceiling filter) | ||
顶板Roof panel | 单层铁皮折弯顶板 Galvanized steel | ||
电控系统 | 喷漆、升温喷漆、烤漆、烘干时间设定、照明开关、故障指示灯、温控仪、电源开关、急停开关、累时器、配限温器。 | ||
Control system | Spraying,risen-temperature spraying,baking,time setting,lighting switch,failure indicator,timperature regulator,power supply switch,emergency stop,time accumulator,limited-temperature device. | ||
电压频率 | 待定 | 最高工作温度 | 80℃ |
Power supply | As request | Highest working temperature | |
光照度 | ≥450LUX | 空载风速Free air speed | ≥0.25m/s |
Illuminance | |||
总功率 | 57.5KW | 颜色：有蓝色、红色和橘黄色供选择 | |
Total power | Option color:blue,orange and white. | ||
