四柱四轮定位举升机
Four post alignment lift
35F4/40F4
产品主要性能
v 定位水平精确可调,是四轮定位的理想设备。
v 前轮转角盘(选购件)位置可调,加长后轮滑板,适合各类车型。
v 具有工作和防断绳双重安全保险,设备平稳可靠。
v 含有二次小车导轨,可选购二次举升小车。
Main performance of products
Ø Accurate positioning level can be adjusted, is the ideal equipment for the four round of positioning.
Ø Front wheel steering wheel (optional parts) position adjustable, extended rear wheel slide, suitable for all types of vehicles.
Ø With work and anti broken rope double safety insurance, smooth and reliable equipment.
Ø Contain two times the car guide rails, can choose to buy two lift car.
型号 | 电源 | 气源 | 功率 | 举升重量 | 举升高度 | 二次(选配)举升重量 | 二次(选配)举升高度 |
Model | Power supply | Air supply | Power | Lifting Capacity | Lifting Height | Second Lifting Capacity(Optional) | Second Lifting Height(Optional) |
35F4 | 380V/3PH or 220V/1PH | 6-8kg/cm² | 2.2KW | 3.5T | 220-1820mm | 2.0T | 375mm |
40F4 | 380V/3PH or 220V/1PH | 6-8kg/cm² | 2.2KW | 4.0T | 246-1896mm | 2.0T | 375mm |
