超薄小剪平板举升机CS30SL/35SL举升机,超薄,平板,汽车维修

剪隐藏超薄平板结构,便于轮胎拆卸及底盘检修。
起始高度低(105、110),无需挖地槽安装。
意大利原装进口液压泵阀,优质电气元件。
具有液压互锁及防爆阀保险装置,起落运行平稳可靠,同步性好。
Main performance of products
Ø The shear type hides the thin flat plate structure, which is convenient for tire dismantling and chassis maintenance.
Ø The initial height is low (105、110), no need to dig trough the installation.
Ø Italy imported hydraulic pump valve, high quality electrical components.
Ø With a hydraulic interlock and explosion-proof valve insurance device, landing operation is stable and reliable, good synchronization.
型号 | 电源 | 气源 | 功率 | 顶板长度 | 举升重量 | 举升高度 |
Model | Power supply | Air supply | Power | Platform Length | Lifting Capacity | Lifting Height |
CS30SL | 380V/3PH or 220V/1PH | 6-8kg/cm² | 2.2KW | 1450mm | 3.0T | 105-1900mm |
CS35SL | 380V/3PH or 220V/1PH | 6-8kg/cm² | 2.2KW | 1450mm | 3.5T | 110-1900mm |
